Features:
- Rack & Fender Ready – Built-in mounts make it easy to add racks and fenders for added versatility.
- Internal Cable Routing – We route shift and break cables through the frame to keep things clean and simple. And it looks great, too.
- DuoTrap S Compatible – DuoTrap S (sold seperately)integrates a Bluetooth/Ant+ sensor into the frame. Log routes and track fitness progress on your computer or smart phone with no external sensor. Works with all major Ant+ wireless players, including Bontrager, Garmin, PowerTrap, and SRM.
- Mechanical Disc Brakes – Reliable stopping power in all conditions, including wet and muddy.
Specs:
Frameset:
- Frame – Alpha Gold Aluminum, DuoTrap S compatible, internal cable routing, flat mount disc, rack & fender mounts, 135x5mm QR
- Fork – FX Steel, flat mount disc, rack mounts, 405mm axle-to-crown, ThruSkew 5mm QR
Wheels:
- Hub front – Formula DC-20, alloy, 6-bolt, 5x100mm QR
- Hub rear – Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR
- Rim – Bontrager Connection, alloy, double-wall, 32-hole, schrader valve
- Spokes – 14g stainless steel
- Tire – Bontrager H2 Comp, wire bead, 30tpi, 700x35c
Drivetrain:
- Shifter – Shimano EF500, 8 speed
- Front derailleur – Shimano Tourney TY710, 34.9mm clamp, top swing, dual pull
- Rear derailleur – Shimano Altus M310
- Crank – Forged alloy, 46/30, chainguard, 170mm length
- Cassette – Shimano HG31, 11-32, 8 speed
- Chain – KMC Z8.3
- Pedal – Wellgo nylon platform
Components:
- Saddle – Bontrager Sport
- Seatpost – Bontrager alloy, 27.2mm, 12mm offset, 330mm length
- Handlebar
- Size: XS, S, M, L – Bontrager Riser, steel, 25.4mm, 30mm rise, 600mm width
- Size: XL, XXL – Bontrager Riser, steel, 25.4mm, 30mm rise, 620mm width
- Grips Bontrager Satellite
- Stem
- Size: XS, S, M – Bontrager alloy, 25.4mm clamp, 10 degree, 90mm length
- Size: L, XL, XXL – Bontrager alloy, 25.4mm clamp, 10 degree, 110mm length
- Headset – 1-1/8” threadless, sealed cartridge bearings
- Brake – Tektro MD-U310 mechanical disc, flat mount, 160mm rotor
Weight:
- Weight – M – 27.95 lbs / 12.68 kg
- Weight limit – This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
