Features:
- Size Small frames have a top tube that dips down as it approaches the seat tube. This makes for a lower standover height, which is good for shorter riders because it allows them to straddle their bike more easily. Larger frames (M and up) have a straight top tube because taller riders typically don’t have the same issues.
- Massive Tire Clearance – Accommodates 700x35c tires with fenders, or a 29″x1.8″ MTB tire without fenders.
- Rack & Fender Ready – Built-in mounts make it easy to add racks and fenders for added versatility.
- Internal Cable Routing – TrekΒ route shift and brake cable through the frame to keep things clean and simple. And it looks great, too.
- Blendr Stem – Bontrager stem technology lets you clip your gear directly to the stem for clean looks, maximum user friendliness.
- DuoTrap S Compatible – DuoTrap S (sold separately) integrates a Bluetooth/ANT+ sensor into the frame. Log routes and track fitness progress on your computer or smart phone with no external sensor. Works with all major ANT+ wireless players, including Bontrager, Garmin, PowerTap, and SRM.
Specs:
Frameset:
- Frame – Alpha Gold Aluminum, DuoTrap S compatible, internal cable routing, rack & fender mounts, post mount disc, kickstand mount, 135x5mm QR
- Fork – SR Suntour NEX, coil spring, preload, hydraulic lockout, 100x5mm QR, 63mm travel
Wheels:
- Hub front Formula DC-20, alloy, 6-bolt, 5x100mm QR
- Hub rear Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR
- Rim Bontrager Connection, alloy, double-wall, 32-hole, schrader valve
- Tire Bontrager GR1 Comp, wire bead, 60 tpi, 700x40c
- Max tire size Frame: 700x45c with fenders, 29×2.10″ without fenders Fork: See manufacturer
Drivetrain:
- Shifter
- Size: S, M, L, XL – Shimano Altus M2010, 9 speed
- Size: S, M, L, XL – Shimano Altus M2010, 2 speed
- Front derailleur – Shimano Acera T3000, 34.9mm clamp, top swing, dual pull
- Rear derailleur – Shimano Altus M2000, long cage
- Crank – Forged alloy, 46/30, chainguard, 170mm length
- Bottom bracket – Sealed cartridge, 68mm
- Cassette – Shimano HG200, 11-36, 9 speed
- Chain – KMC X9
- Pedal – Wellgo M141, resin body, alloy cage
Components:
- Saddle – Bontrager Sport
- Seatpost – Bontrager alloy, 27.2mm, 12mm offset, 330mm length
- Handlebar
- Size: S, M – Bontrager alloy, 31.8mm, 15mm rise, 600mm width
- Size: L, XL – Bontrager alloy, 31.8mm, 15mm rise, 660mm width
- Grips – Bontrager Satellite
- Stem
- Size: S – Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 70mm length
- Size: M, L – Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 80mm length
- Size: XL – Bontrager alloy, 31.8mm clamp, Blendr compatible, 7 degree, 100mm length
- Headset – 1-1/8” threadless, sealed cartridge bearings
Weight:
- Weight M – 29.15 lbs / 13.22 kg
- Weight limit This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
