Features:
- Make it your own:Β Customize your bike with fenders, racks, bottle cages, and more to make it your own.
- Suspension Fork: Shock-absorbing fork allows the front wheel to travel up and down over bumps while the handlebars stay steady, for a comfortable, controlled ride.
- Massive Tire Clearance: Accommodates 700x45c tires with fenders, or a 29″x2.1″ MTB tire without fenders.
- Rack & Fender Ready:Β Built-in mounts make it easy to add racks and fenders for added versatility.
- Internal Cable Routing:Β We route shift and brake cables through the frame to keep things clean and simple. And it looks great, too.
Specs:
- Frameset:
- Frame – Alpha Gold Aluminum, DuoTrap S compatible, internal cable routing, rack & fender mounts, post mount disc, kickstand mount, 135x5mm QR
- Fork – SR Suntour NEX, coil spring, preload, 100x5mm QR, 63mm travel
- Wheels:
- Hub front – Formula DC-20, alloy, 6-bolt, 5x100mm QR
- Hub rear – Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR
- Rim – Bontrager Connection, alloy, double-wall, 32-hole, schrader valve
- Tire – Bontrager GR1 Comp, wire bead, 60 tpi, 700x40c
- Max tire size – Frame: 700x45c with fenders, 29×2.10″ without fenders Fork: See manufacturer
- Drivetrain:
- Shifter – Shimano EF500, 8 speed
- Front derailleur – Shimano Tourney TY710, 34.9mm clamp, top swing, dual pull
- Rear derailleur – Shimano Altus M310
- Crank – Forged alloy, 46/30, chainguard, 170mm length
- Bottom bracket – Sealed cartridge, 68mm
- Cassette – Shimano HG31, 11-32, 8 speed
- Chain – KMC Z8.3
- Pedal – Wellgo nylon platform
- Components:
- Saddle – Bontrager Sport
- Seatpost – Bontrager alloy, 27.2mm, 12mm offset, 330mm length
- Handlebar:
- Size: S, M – Bontrager Riser, steel, 25.4mm, 30mm rise, 600mm width
- Size: L, XL – Bontrager Riser, steel, 25.4mm, 30mm rise, 620mm width
- Grips – Bontrager Satellite
- Stem:
- Size: S, M – Bontrager alloy, 25.4mm clamp, 10 degree, 90mm length
- Size: L, XL – Bontrager alloy, 25.4mm clamp, 10 degree, 110mm length
- Headset – 1-1/8” threadless, sealed cartridge bearings
- Brake – Tektro MD-M280 mechanical disc, 160mm rotor
- Weight:
- Weight – M – 13.54 kg / 29.86 lbs
- Weight limit – This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).
